MyVSCAN-BS

MY-VSCANBS is a mobile backscatter X-ray inspection scanner designed for non-intrusive inspection of vehicles and cargo without the need for unloading. Utilizing advanced backscatter X-ray technology, the system delivers high detection capability for concealed items, including explosives, narcotics, cash, and other contraband.

The MY-VSCANBS is available in two configurations: Standard and High-Penetration (HP). The High-Penetration configuration operates at higher X-ray energy to provide enhanced penetration and superior image quality when inspecting dense or heavily loaded vehicles while the system also maintains a low radiation dose, ensuring safety for operators, drivers, and the surrounding environment during High penetration scanning.

MY-VSCANBS can be mounted on a wide range of truck chassis and trailers.

Backscatter X-ray technology
High Penetration Scanning
2 Way Operational Modes
Powered By AI

Mobile Backscatter Inspection Scanner

Advantages

High Image Quality

Bakcscatter Technology

Safe To Scan

Fully Automated Operation

High Throughput

Low Radiation Dose

General Specifications

certified by sirim
General SpecificationDescription
Beam DirectionSide View Scanning
Operational Modes- Mobile Mode
- Stationary with active Radar
X-ray TechnologyBackscattering Technology
X-ray Energy- Standard Scanning (225 kV)
- High Penetration Scanning (300 kV)
Penetration7 mm
Engine TypeDiesel
Payload Weight5 Ton
Transmission TypeAutomatic (AT)
Min. Number of Operators1

Image Generate System

* Comply to ANSI N42.46-2008 and IEC62523

FeaturesDescription
Data Storage4096 grey levels stored
Image PresentationB/W, color
Digital Video Memory1280 x 1024/24 bit
Image Evaluation FunctionsVARI-MAT ,0²,OS,HIGH,NEG,electronic zoom; step-less enlargement up to 64 times
Edge EnhancementYes
